Garvan Acoustic WA138 е високопроизодителен outdoor субуфер от серията Loto™. Мощността му е 1200W AES power, конструкцията ми е тип bass-reflex. Възпроизвежда ниски честоти до 34Hz и корпусът му е от HPL или Corian®. Конструкцията е от неръждаема стомана AISI 316L. Перфектно допълва аудио системи за градини, тераси, басейни, плажни клубове и всякакви големи открити пространства.

Garvan Acoustic WA138 – Info

Garvan Acoustic Loto™ Collection

Описание

Garvan Acoustic WA138

High-performance outdoor subwoofer WA138

WA138 is the outdoor subwoofer from the Loto™ Collection, designed to deliver deep, powerful bass in gardens, terraces, pool areas, beach clubs and large outdoor spaces.
The 15-inch woofer, bass-reflex design and 1,200 W AES power handling extend low-frequency reproduction down to 34 Hz, completing outdoor audio systems for both residential and professional installations.
The HPL or Corian® enclosure, combined with the AISI 316L stainless-steel structure, brings together high acoustic performance, weather resistance and architectural integration.

Deep bass in open spaces

Power and control for high-performance outdoor audio systems

In outdoor environments, low frequencies disperse more easily because there are no walls or reflective surfaces. WA138 is designed to deliver depth, sound pressure and impact even in large open spaces.

The 15-inch woofer and bass-reflex design extend reproduction down to 34 Hz, complementing outdoor speakers used in gardens, terraces, pool areas, hospitality venues and open-air locations.

  • Frequency response: 39–150 Hz (-3 dB)
  • Frequency range: 34–150 Hz (-10 dB)
  • Sensitivity: 91 dB (1 W / 1 m)
  • Calculated maximum SPL: 134 dB @ 1 m

Materials designed for outdoor use

HPL or Corian®, stainless steel and weather protection

The WA138 enclosure can be made from HPL or Corian®, materials selected to combine durability, stability and integration into outdoor architectural projects.

The support structure is made from AISI 316L stainless steel, while IP35 protection makes the subwoofer suitable for permanent installation in outdoor environments exposed to the weather.

  • Enclosure in HPL or Corian®
  • Support in AISI 316L stainless steel
  • Environmental protection IP35
  • Operating temperature: from -25 °C to +70 °C
  • Net weight: 33,3 kg
  • Manufactured Made in Italy

Installation and amplification

Floor placement, dedicated preset and system protectin

WA138 is designed for freestanding installation and is supplied with a base for ground placement. It can be positioned on terraces, outdoor flooring and landscaped areas, integrating into the project without requiring recessed installation work.

The subwoofer has a nominal impedance of 4 Ω and requires suitable equalisation, filtering and protection. Garvan presets and a dedicated amplifier are available to provide controlled performance and protect the woofer at the lowest frequencies.

  • Installation freestanding
  • Ground placement base included
  • Nominal impedance: 4 Ω
  • Garvan presets and equalisation recommended
  • Recommended high-pass filter: 40 Hz – 48 dB/octave

WA138: the outdoor giant

1,200 W of power for deep bass in open spaces

An in-depth look at WA138, the Garvan subwoofer designed to reproduce powerful, controlled low frequencies even in large outdoor environments.

The video shows the product’s dimensions, construction and main features, together with the solutions developed to combine acoustic performance, durability and integration into outdoor spaces.

  • Woofer: 15 inches
  • Power handling: 1,200 W AES
  • Low frequencies down to 34 Hz
  • Enclosure in HPL or Corian®
  • Residential and professional applications

SINGLE LOUDSPEAKER PERFORMANCE


Installation Type   Outdoor 360° subwoofer
AES Power Handling   1200 W
Continuous Power Handling ***   2400 W
Sensitivity 2,83V / 1m ****   94 dB
Sensitivity 1W/1m ****   91 dB
Calculated Maximum SPL @ 1m*   134 dB


TRANSDUCER


Type   Subwoofer
Nominal size   1x WF 380mm
Nominal Impedance   4Ω
Loudspeaker EQ   Required, Garvan Preset EQ, Filter and protection available
Recommended High-Pass Filter Protection   40Hz with 48 dB/Oct. High-pass Filter
Frequency Response (-3 dB)   39 Hz – 150 Hz **
Frequency Range (-10 dB)   34 Hz – 150 Hz **
Nominal Coverage Angle (1 KHz - 10 kHz)   360°
Side Coverage (1500Hz - 10kHz)   -0 dB
Rear Coverage (1500Hz - 10kHz)   -0 dB


PHYSICAL


Cabinet Material   HPL or Corian®
Ground mounting base   AISI 316L stainless steel
Protective grille   AISI 316 stainless steel painted black


ENVIRONMENTAL FEATURES


Environment of Use   Outdoor environments
Operating Temperature Range *****   -25 °C to 70 °C (-13 °F to 158 °F)
Environmental protection   IP35
Connectors   External multi-wire cable
Net Weight   53.6 Kg (HPL) / 59.5 Kg (Corian®)
Product Dimensions   500 × 500 × 657 mm


* Maximum SPL calculated from sensitivity and power handling specifications, using a signal with crest factor 4 (12dB), exclusive of power compression.
** With dedicated preset
*** Power on Continuous Program is defined as 3 dB greater than the Nominal rating.
**** average SPL measured from 200 Hz to 1,5 kHz
***** Valid with the dedicated start-up and maintenance procedure.
